Manual Motor Starters
Ex9S

Product Description

Features:
Ex9S Manual Motor Starters provide manual isolation, manual motor control, and overcurrent protection. They are electro-mechanical devices combining the functions below in one unit.

• Disconnect for Motor Branch Circuit
• Manual Motor Control (automatic when used with contactor)
• Branch-Circuit Short Circuit Protection (Magnetic Protection)
• Overload Protection (Thermal Protection) – Trip Class 10

The National Electrical Code requires an individual Motor Branch Circuit to be protected by a UL/CSA Listed Fuse, Circuit breaker or Self Protected Combination Motor Controller.

Available as:
• Up to 80A @600Vac
• UL 60947-4-1 Type E Self Protection-Ex9S32 and Ex9S80
• UL 60947-4-1 Type F Group Motor Protection-Ex9S32
• Built-in fault indication
• Full range of accessories
• Lockable handle

Certifications:
• UL listed
• CCC Certified
• NOM Certified
• RoHs Compliant

Standards Compliance:
• UL 60947-1; UL 60947-4-1
• IEC/EN 60947-1, IEC/EN 60947-2, IEC/EN 60947-4-1,IEC/EN 60947 -5-1
• GB 14048.1, GB 14048.2, GB 14048.4
• CSA 22.2 NO. 60947-1,CSA 22.2 NO. 60947-4-1

Ex9S32:

Ex9S80:

Accessories

Auxiliary Contact Blocks
Electrical Trip Unit
Mounting Accessories
Wiring Accessories
Enclosures
Operation Handle
Busbars
