NOARK IEC Contactors

Product Description

IEC Contactors - Ex9C Product

Features:
Ex9C series contactors are suitable for a broad range of motor control applications. With many available accessories and options, these contactors have ampacity ratings from 6A to 1000A at 600Vac and can be applied in systems up to 600Vac. A range of overload relays are available in a variety of frame sizes to fit respective contactors of given rated current.

• Nine frame sizes with rated current up to 1000A at 690V AC-3
• Coil control voltage from 24-600Vac and 24-500Vdc
• Wide range electronic coil available for 9-500A contactors features built-in surge suppression
• DIN rail 35 mm and panel mountable

Certifications:
• UL 508 Listed, File Number E353866, UL 60947-1 and 60947-4-1
• Certified to CSA C22.2 No. 14
• IEC/EN 60947-4-1
• CE Approved
• CCC Certified

Ex9CS/CSR 6 -12 Amperes Miniature

• Built-in auxiliary contacts on 3-pole; additional auxiliary contacts are front mounted
• Non-Reversing

• Built-in auxiliary contacts on 3-pole; additional auxiliary contacts are front mounted
• Reversing

Accessories

Front Mount Auxiliary Contact
• For contactors Ex9CS and Ex9CSR
• Field installable
• One unit used with a contactor

Surge Suppressor Block
• Reduces voltage peaks in control circuit
• Versions with varistor and RC circuit technology
• Includes cable lugs for connecting to contactor terminals

Star Delta Wiring Kit (SDWK)

Ex9C 9-1000 Amperes Standard

• Built-in auxiliary contacts; 1NO/1NC additional auxiliary contacts are front or side mounted
• Non-Reversing

Accessories

Front Mount Auxiliary Contact
• Field installable
• One unit used with a contactor

Mechanical Interlock

Surge Suppressor Block
• Reduces voltage peaks in control circuit
• Versions with varistor and RC circuit technology
• Includes cable lugs for connecting to contactor terminals

Side Mount Auxiliary Contact
• Field installable
• One unit used with a contactor on the left side, another unit on the right side

Power Connection

Time Delay Relay

Star Delta Wiring Kit

Terminal Cover

Surface mount

Ex9CR 9-500 Amperes Standard Reversing

• Built-in auxiliary contacts; additional auxiliary contacts are front or side mounted
• Reversing
• Reversing contactor is comprised of 2 contactor joined by a mechanical interlock and power connection on 115A and above.

• Built-in auxiliary contacts; additional auxiliary contacts are front or side mounted
• Reversing
• Reversing contactor is comprised of 2 contactor joined by a mechanical interlock and power connection

Ex9CR 115-500 Amperes Standard Reversing

• Built-in auxiliary contacts; additional auxiliary contacts are front or side mounted
• Reversing
• Reversing contactor is comprised of 2 contactor joined by a mechanical interlock and power connection

Ex9CDS

Features:
Ex9CDS are general purpose contactors used mainly for controlling 3-phase motors and power circuits up to 600 Vac. This entry level line includes magnetic coils and basic accessories for front and side mounting.

• 5 kA @ 600 Vac
• Built-in NO or NC auxiliary contacts on 9-32A frames
• 3 and 4-pole versions including 2NO+2NC and 4NO configurations
• 95 A mounts on standard 35mm DIN rail (40-95A can also mount on 75 mm DIN rail)
• 12 month warranty

Certifications:
• UL Listed, File Number E353866
• Certified for Canada CSA standards 22.2 No. 14 under cUL testing
• IEC/EN 60947
• CE Compliant

Ex9CDS 9-95 A

• Auxiliary contacts are side mounted; front mounted also available.

Accessories

Front Mount Auxiliary Contact
• For contactors Ex9CD
• Field installable
• One unit used with a contactor
